What is the Wallbox Pulsar Max?
The Pulsar Max is a compact home charger from Wallbox, which says it builds on its Pulsar Plus. It comes in 7.4 kW single-phase and 11 kW or 22 kW three-phase versions, tethered or with a Type 2 socket, in white or black.
Charging power: 7.4 kW single-phase, 11 or 22 kW three-phase
Wallbox's UK datasheet lists 7.4 kW at 230 V and 32 A on a single-phase supply, 11 kW at 400 V and 16 A on three-phase, and 22 kW at 400 V and 32 A on three-phase. The three-phase versions need a three-phase supply. Current is configurable from 6 A up to the rated current. The rate your car charges at is also limited by its own onboard charger.
Tethered or untethered: the cable options
The tethered version has a 5 m or 7 m Type 2 cable. The socket version has a Type 2 socket with a shutter; Wallbox says the cable can be locked temporarily so it works as a tethered unit, and that a socket suits anyone who needs a cable longer than 7 m.
Solar charging with an add-on sensor
Wallbox says solar charging needs one of its power meters. With a meter installed, you can charge with 100% solar energy or a mix of solar and grid, set in the Wallbox app. For three-phase Pulsar units, Wallbox's Solar Charging 3P Optimisation switches charging to single-phase when the solar surplus is too low for three-phase charging.
Smart charging with Octopus, E.ON Next and OVO
The Wallbox app schedules charging, sets departure times and target battery levels, and monitors energy use; it connects over Bluetooth nearby or Wi-Fi remotely.
On the energy suppliers' own lists (checked 2 November 2026):
- Octopus Energy lists the Wallbox Pulsar Max as supported for Intelligent Octopus Go.
- OVO Energy does not list Wallbox for Charge Anytime.
- E.ON Next does not list Wallbox for Next Drive Smart.
Load balancing, earthing and installation
Static load management is included. Dynamic load management, solar charging and external MID metering need an external meter, according to the datasheet. The charger provides 6 mA DC residual current detection, and an external Type A RCCB is required. Wallbox's part number structure includes "UK O-PEN protection" as a feature code, and its UK declaration of conformity lists UK O-PEN protection, so UK models have PEN fault protection built in. Wallbox says the Pulsar Max is designed to be installed in 10 minutes.
App, Wi-Fi and connectivity
The Pulsar Max connects over Wi-Fi and Bluetooth, and Wallbox's 2026 datasheet adds a wired Ethernet connection. It has an RFID reader, and an RFID card is supplied. It shows its status with a halo RGB LED. It supports OCPP and Wallbox's partner API and SDK.
Size, dimensions and weatherproofing
The tethered version measures 198 x 201 x 99 mm without its cable and weighs 1.3 kg without the cable. The socket version measures 204.3 x 313 x 142.5 mm and weighs 2.5 kg. Wallbox's 2026 datasheet rates it IP55 and IK09, and it operates from -30°C to 50°C, at full capacity up to 40°C. The datasheet lists compliance with the UK Smart Charging Regulations.
Warranty: 5 years
Wallbox lists a 5-year warranty for the Pulsar Max.
